Science never takes a holiday

Your research doesn't pause, and neither should your innovation. Take advantage of our limited time offer on the Atlas Syringe Pump and Atlas XL Syringe Pump and maintain your experimental momentum.

Atlas Syringe Pump

Our best selling Atlas Syringe Pump and Atlas XL Syringe Pump are the perfect addition to your lab. Designed to work as standalone syringe pumps with your existing batch reactors or controlled by Syrris’ Atlas HD automated jacketed reactor or Atlas PC Software, they offer a small footprint and are lightweight enough to be easily moved between lab benches.

Don’t miss out on our limited time offer, get in touch today to receive 30% off your Atlas Syringe Pump or Atlas XL Syringe Pump!

Advanced dosing protocols

Atlas Syringe Pump and Atlas XL Syringe Pump enable versatile volumetric dosing or sampling and have a wide range of dosing modes; dual, pH control, temperature-dependent, pseudo-gravimetric, and continuous. Advanced dosing protocols eliminate tedious or tricky tasks and free up your time in the laboratory.

  • pH controlled dosing
    Combined with an Atlas pH probe and node, Atlas Syringe Pumps can automatically dose an acid and/or base to keep the pH or your reaction within a defined range. Automated pH control can save chemists valuable time by removing the need to manually add small amounts of acid/base over the course of a reaction.

    A wealth of chemical and biological transformations exist that show a strong correlation between pH and rate of reaction. Many starting materials, reactive intermediates, and products are sensitive to acids/bases, so accurate pH control is essential for reactions to progress reliably. Automated and precise pH control enables chemists more control over certain chemistries, such as catalytic reactions, bio-reactions, and enzymatic reactions, and enables measurement of reaction kinetics and conversion.

    		 Syrris Atlas Syringe Pump ph Control Graph

    Automated pH controlled dosing
    A graph showing Atlas Syringe Pump controlling the pH level of an un-buffered solution
  • Temperature-dependent dosing
    Atlas Syringe Pump offers temperature-dependent dosing, allowing you to pause reagent addition until your reactor temperature is within a defined range. Automatically mitigate against exotherms and endotherms, increasing laboratory safety and saving valuable time.

    Accurate temperature control and monitoring is vital for accurately predicting the scale-up of chemical processes, and in biochemistry, temperature control is critical to avoiding denaturing or damaging the product.

    Automated temperature-dependent dosing
    The reactor temperature, circulator temperature, and cumulative dosed volume of NaOH (aq) for the temperature-dependent dosing experiment are shown in this graph
  • Pseudo-gravimetric dosing
    Atlas Syringe Pump can perform pseudo-gravimetric dosing, a powerful technique for the accurate introduction of a reagent into a reactor, utilizing a mass balance to ensure that the desired quantity of reagent is dosed. In test experiments, the process gave excellent results with an error in dosing of less than or equal to 0.1% of the required dosed amount.

    		 Syrris Atlas Syringe Pump Pseudo-gravimetric dosing setup

    Pseudo-gravimetric dosing set-up
    A photograph from test experiments demonstrating pseudo-gravimetric dosing using Atlas Syringe Pump paired with Ohaus Pioneer Balance and Atlas Software
  • Autosampling
    Atlas Syringe Pump enables automated sampling of up to 6 samples with each syringe/valve, directly through the syringe pump or through the Atlas PC Software.

    Chemists can define a number of variables for complete control, including; the number of samples needed; the volume of each sample; the time it takes to aspirate the sample; the delay before the first sample is taken; and the delay between each sample.

    		 Syrris Atlas Syringe Pump autosampling

    Atlas Syringe Pump autosampling software preview

Customer story: using Atlas Syringe Pumps for gold nanoparticle production

Researchers at Midatech Biogune, a Spanish biotechnology company, are using Syrris Atlas Syringe Pumps with Atlas automated jacketed reactor systems to produce custom-made functionalized gold nanoparticles for medicinal use.

Our Atlas Potassium reactors, with pH control and an Atlas XL Syringe Pump, have allowed us to scale­up production, enabling variables such as pH and temperature to be tightly controlled.”

2 sizes for different chemistry needs

Choose from the Atlas Syringe Pump and the Atlas XL Syringe Pump depending on the chemistry your lab conducts. Both pumps offer equally smooth flow, 6 bar pressure, 2 syringes, 2 valves, up to 6 ports per valve, and all 6 main modes of operation. Multi port valves dose many reagents to the same reactor or multiple reactors and remove the need for manual handing or filling of syringes.

Atlas Syringe Pump offers a flow rate of 0.5 μL/min to 20,000 μL/min (20 mL) and syringe sizes from 50 μL to 5000 μL.

The Atlas XL Syringe Pump offers a flow rate of 0.005 mL/min to 200 mL/min and syringe sizes from 0.5 mL to 50 mL.

See the full breakdown of flow rates and syringe sizes here

Standalone, PC, or Atlas HD Base control

Atlas Syringe Pumps have been designed to work as standalone syringe pumps, using the click wheel control and screen to select and configure dosing methods.

Atlas Syringe Pumps offer 6 main modes of operation:

      1. Dual Dosing Mode allows independent control of each syringe and associated valve, enabling chemists to dose with one syringe and autosample using the other. Available commands include: dose a particular volume; pump at a particular flow rate; dose one reagent to many jacketed reactors; sophisticated profiles; and auto-sampling (connect the Autosampler and probe to enable automated sampling of up to 6 samples with each syringe/valve)
      2. pH Control Mode can automatically dose an acid and/or base to keep the pH or your reaction within a defined range
      3. Temperature Control Dosing Mode enables the Atlas Syringe Pump to dose key chemicals based on a set temperature, offering safe dosing into exothermic reactions
      4. Continuous-Dosing Mode enables 2 syringe pumps to work together to produce 1 continuous flow, i.e. one is refilling while the other is dispensing
      5. Atlas HD Base Control Mode enables an Atlas HD automated jacketed reactor (or Reactor Master automation unit) to control the Atlas Syringe Pump as part of an automated temperature and stirrer speed profile
      6. PC Control Mode controls the Atlas Syringe Pump from Atlas PC Software, enabling the pump to be used in complex, multi-step automated reactions

Performance and flexibility

Atlas Syringe Pumps can perform dual-dosing, continuous dosing, pH control, and temperature-dependent control in Standalone mode, enabling chemists to move the pump around the lab for use with different reactors.

The valves are user changeable and are available in a number of different port options. Each of the ports on each valve can be configured to be an input or output; with a 6 port valve it is possible to pump from up to 5 sources to one reactor, etc. per syringe. The syringes are also user changeable and come in a variety of sizes, corresponding to a variety of flow rate ranges. Use the Atlas Pump Pressurized Input Store to enable an inert gas blanket over the samples to be pumped and to minimize cavitation/bubbles.

An Introduction to Atlas Syringe Pump
An overview of Atlas Syringe Pump, Syrris' versatile, bestselling batch chemistry pump that takes care of all your laboratory dosing needs.

Don't miss our limited offer

Offer available from 05 August to 30 September 2024 from Syrris. Grab an Atlas Syringe Pump or Atlas XL Syringe Pump at 30% off now.

Further information

  • Terms & conditions
    1. Offer only valid on orders received from 5 August through to 30 September.
    2. Offer can not be used in conjunction with other offers, discounts or special promotions.
    3. Shipping costs not included and all other standard Syrris T&C’s apply – please see our website.
    4. We reserve the right to withdraw, amend or extend this offer at any time without prior notice.
  • Flow rate range for Atlas Syringe Pump
     Flow rate range for Atlas Syringe Pump
     Min flow rate μL/min  Max flow rate μL/min
    Syringe size (μL)  Continuous flow Dual dose mode   Continuous flow  Dual dose mode
     50 10 0.5 200 200
     100 20 1 400 400
     250 50 2.5 1000 1000
     500 100 5 2000 2000
     1000 200 10 4000 4000
     2500 500 25 10000 10000
     5000 1000 50 20000 20000
  • Flow rate range for Atlas XL Syringe Pump
     Flow rate range for Atlas XL Syringe Pump (in mL)
     Min flow rate mL/min  Max flow rate mL/min
    Syringe size (mL)  Continuous flow Dual dose mode   Continuous flow  Dual dose mode
     0.5 0.1 0.005 2 2
    1 0.2 0.01 4 4
    2.5 0.5 0.025 10 10
    5 1 0.05 20 20
    10 2 0.1 40 40
    25 5 0.25 100 100
    50 10 0.5 200 200

What our customers say

Thanks again for your support! The pump arrived yesterday…and we started testing immediately. You did not promise too much at all. It runs quietly, smoothly and the user interface is – as you said – straightforward. The size and design fit perfect to our needs and I love the metal finish.

Dr Adrian Press, Jena University Hospital, Germany
Get in touch
